Intel DQ67EP User Manual

Desktop Board Features
13
Table 2. Intel Desktop Board DQ67EP Components
Label Description
A Back panel connectors
B Battery
C Serial port header
D 12 V processor core voltage connector (2 x 2 pin)
E SATA connectors
F Front panel USB 2.0 header
G PCI Express Mini Card connector
H Main power connector (2 x 12 pin)
I Standby power indicator LED
J System fan header
K Front panel USB 2.0 header
L Speaker
M Front panel USB 2.0 header
N Front panel header
O Alternate front panel power LED header
P Intel
®
Fast Call for Help (Intel
®
FCFH) header
Q Chassis intrusion header
R BIOS configuration jumper block
S DDR3 DIMM 2 socket
T DDR3 DIMM 1 socket
U Processor socket
V PCI Express 2.0 x16 add-in card connector
W Processor fan header
X Intel
®
Management Engine BIOS Extension (Intel
®
MEBX) reset header
Y S/PDIF header
Z Internal mono speaker header
AA Front panel audio header
