Intel Desktop Board DQ67EP Product Guide
54
S/PDIF Header
Figure 20, H shows the location of the S/PDIF output header. Table 13 lists the pin
assignments and signal names for the S/PDIF output header.
Table 13. S/PDIF Header Signal Names
Pin Description
1 Ground
2 S/PDIF Out
3 Key (no pin)
4 +5 VDC
Internal Mono Speaker Header
The internal mono speaker header is shown in Figure 20, I. Table 14 lists the pin
assignments and signal names for the internal mono speaker header.
Table 14. Internal Mono Speaker Header
Pin Signal Name
1 −
2 +
