Intel Desktop Board DX79SI Technical Product Specification
14
Table 3. Components Shown in Figure 1
Label
Description
A
Front panel audio header
B
PCI Express x1 add-in card connector
C S/PDIF out header
D
PCI Express 3.0 x16 add-in card connector (x8 electrical)
E
Piezoelectric speaker
F
Conventional PCI add-in card connector
G PCI Express 3.0 x16 add-in card connector
H
PCI Express x1 add-in card connector
I
PCI Express 3.0 x16 add-in card connector
J
Rear chassis fan header
K Battery
L
Back panel connectors
M
Processor fan header
N
DIMM 1 (Channel A, DIMM 0)
O DIMM 5 (Channel B, DIMM 0)
P
DIMM 2 (Channel A, DIMM 1)
Q
DIMM 6 (Channel B, DIMM 1)
R
LGA 2011 processor socket
S 12 V processor core voltage connector (2 x 4 pin)
T
DIMM 8 (Channel D, DIMM 1)
U
DIMM 4 (Channel C, DIMM 1)
V
DIMM 7 (Channel D, DIMM 0)
W DIMM 3 (Channel C, DIMM 0)
X
Main power connector (2 x 12 pin)
Y
Remote thermal probe header
Z
Front chassis fan header
AA 3.0 Gb/s SATA connectors (black) and 6.0 Gb/s SATA connectors (blue)
BB
Intel X79 Express Chipset
CC
Front panel USB 2.0 headers (4)
DD
Consumer IR emitter (output) header
EE BIOS Setup configuration jumper block
FF
Power Fault LED
GG
Front panel USB 3.0 connector
HH
Alternate front panel power LED header
II Consumer IR receiver (input) header
JJ
Voltage measurement test points
KK
Front panel header
LL
Post Code LED display
MM Front panel IEEE 1394a header
NN
Onboard Reset button
OO
Onboard Power button
PP
Chassis intrusion header
QQ Auxiliary fan header
RR
Board Status LEDs
