Technical Reference

Table 12. Component-side Connectors and Headers Shown in Figure 13

Item/callout

from Figure 13

Description

A Front panel audio header

B PCI Express x1 add-in card connector

C S/PDIF out header

D PCI Express 3.0 x16 add-in card connector (x8 electrical)

E Conventional PCI add-in card connector

F PCI Express 3.0 x16 add-in card connector

G PCI Express x1 add-in card connector

H PCI Express 3.0 x16 add-in card connector

I Rear chassis fan header

J Processor fan header

K 12 V processor core voltage connector (2 x 4 pin)

L Main power connector (2 x 12 pin)

M Remote thermal probe header

N Rear chassis fan header

O 3.0 Gb/s SATA connectors (black) and 6.0 Gb/s SATA connectors (blue)

P Front panel USB 2.0 header

Q Front panel USB 2.0 header

R Front panel USB 2.0 header

S Front panel USB 2.0 header

T Consumer IR emitter (output) header

U Front panel USB 3.0 connector

V Consumer IR receiver (input) header

W Alternate front panel power LED header

X Front panel header

Y Front panel IEEE 1394 a header

Z Chassis intrusion header

AA Auxiliary fan header
