4 Error Messages and Beep Codes
4.1 Speaker
The board-mounted speaker provides audible error code (beep code) information
during POST.
For information about Refer to
The location of the onboard speaker Figure 1, page 13
4.2 BIOS Beep Codes
Whenever a recoverable error occurs during POST, the BIOS causes the board’s
speaker to beep an error message describing the problem (see Table 37).
Table 37. BIOS Beep Codes
Type Pattern Frequency
F2 Setup/F10 Boot Menu
Prompt
One 0.5 second beep when BIOS is ready to
accept keyboard input
932 Hz
BIOS update in progress None
Video error On-off (1.0 second each) two times, then
2.5-second pause (off), entire pattern repeats
(beeps and pause) once and the BIOS will
continue to boot.
932 Hz
When no VGA option ROM is
found.
Memory error On-off (1.0 second each) three times, then
2.5-second pause (off), entire pattern repeats
(beeps and pause) until the system is powered
off.
932 Hz
Thermal trip warning Alternate high and low beeps (1.0 second each)
for 8 beeps, followed by system shut down.
High beep 2000 Hz
Low beep 1500 Hz
