1.7.1.3 Digital Visual Interface (DVI-I)
The DVI-I port supports both digital and analog DVI displays. The maximum
supported resolution is 1900 x 1200 (WUXGA). The DVI port is compliant with the
DVI 1.0 specification. DVI analog output can also be converted to VGA using a DVI-
VGA converter.
Depending on the type of add-in card installed in the PCI Express x16 connector, the
DVI port will behave as described in Table 6.
Table 6. DVI Port Status Conditions
PCI Express x16 Connector Status
DVI Digital (DVI-D)
Port Status
DVI Analog (DVI-A)
Port Status
(Note 1)
No add-in card installed Enabled Enabled
Non-video PCI Express x1 add-in card
installed
Enabled Enabled
PCI Express x16 add-in card installed
Disabled
Enabled
(Note 2)
Notes:
1. DVI analog output can also be converted to VGA with a DVI-VGA converter.
2. May require BIOS setup menu changes.
1.7.1.4 DisplayPort*
DisplayPort is a digital communication interface that utilizes differential signaling to
achieve a high bandwidth bus interface designed to support connections between PCs
and monitors, projectors, and TV displays. DisplayPort is suitable for display
connections between consumer electronics devices such as high definition optical disc
players, set top boxes, and TV displays. DisplayPort output can also be converted to
HDMI* using a DisplayPort-HDMI converter.
DisplayPort’s maximum supported display resolution is 2560 x 1600 at 60 Hz refresh
with a 16:10 aspect ratio (WQXGA). DisplayPort 1.1 adds support for High Bandwidth
Digital Content Protection (HDCP) version 1.3. HDCP support enables viewing of
protected content from Blu-ray and HD-DVD optical media over DisplayPort 1.1
connections.
Table 7. DisplayPort Status Conditions
PCI Express x16 Connector Status DisplayPort Status
No add-in card installed Enabled
Non-video PCI Express x1 add-in card installed
Enabled
PCI Express x16 add-in card installed Enabled
(Note)
Note: May require BIOS setup menu changes.
For information about Refer to
DisplayPort technology http://www.displayport.org
