Intel Desktop Board DZ68BC Technical Product Specification
44
Table 13. Board Status LEDs
Item/Callout
in Figure 8 LED Name
LED
Color Supported Modes Control Source
A Hard Drive Activity Blue On/Off Hard drive
controller(s)
B CPU Hot Red On/Off Discrete circuit
C VR Hot Red On/Off Discrete circuit
D Watch Dog Fire / Back to
BIOS
Red On/Off/Flash BIOS
E CPU Initialization Green On/Off/Flash BIOS
F Memory Initialization Green On/Off/Flash BIOS
G Video Initialization Green On/Off/Flash BIOS
H USB Initialization Green On/Off/Flash BIOS
I Hard Drive Initialization Green On/Off/Flash BIOS
J Option ROM Initialization Green On/Off/Flash BIOS
K Operating System Start Green On/Off/Flash BIOS
L IERR#_LED Green On/Off/Flash BIOS
M PME#LED Green On/Off/Flash BIOS
