Intel Desktop Board DZ68BC Technical Product Specification
52
Table 15. Component-side Connectors and Headers Shown in Figure 12
Item/callout
from Figure 12
Description
A Conventional PCI bus add-in card connector
B Conventional PCI bus add-in card connector
C S/PDIF out header
D PCI Express 2.0 x16 connector (x8 electrical; x16 compatible)
E PCI Express x1 bus add-in card connector
F Conventional PCI bus add-in card connector
G PCI Express 2.0 x16 connector
H Rear chassis fan header
I PCI Express x1 bus add-in card connector
J 12 V processor core voltage connector (2 x 4 pin)
K Processor fan header
L Debug header
M Consumer IR receiver (input) header
N Consumer IR transmitter (output) header
O Main power connector (2 x 12)
P Front panel header
Q Front chassis fan header
R Alternate front panel power LED header
S SATA 6.0 Gb/s connector through a Marvell controller (light blue)
T SATA 6.0 Gb/s connector through the PCH (blue)
U SATA 3.0 Gb/s connectors through the PCH (black)
V Serial port header
W Front panel USB 2.0 header
X Front panel USB 2.0 header
Y Front panel USB 2.0 header
Z Front panel USB 2.0 header
AA Chassis intrusion header
BB Front panel USB 3.0 connector
CC IEEE 1394a front panel header
DD Auxiliary fan header
EE Front panel audio header
