Appendix C: POST Error Messages and Handling Intel
®
Server Board S5500BC TPS
Intel order number: E42249-003 Revision 1.0
94
Appendix C: POST Error Messages and Handling
Whenever possible, the BIOS outputs the current boot progress codes on the video screen.
Progress codes are 32-bit quantities plus optional data. The 32-bit numbers include class,
subclass, and operation information. The class and subclass fields point to the type of hardware
that is being initialized. The operation field represents the specific initialization activity. Based on
the data bit availability to display progress codes, a progress code can be customized to fit the
data width. The higher the data bit, the higher the granularity of information that can be sent on
the progress port. The progress codes may be reported by the system BIOS or option ROMs.
The Response section in the following table is divided into three types:
 Minor: The message displays on the screen or in the Error Manager screen. The
system continues booting with a degraded state. The user may want to replace the
erroneous unit. The setup POST error Pause setting does not have any effect with this
error.
 Major: The message is displayed in the Error Manager screen and an error is logged to
the SEL. The setup POST error Pause setting determines whether the system pauses
to the Error Manager for this type of error where the user can take immediate corrective
action or choose to continue booting.
 Fatal: The message is displayed in the Error Manager screen, an error is logged to the
SEL, and the system cannot boot unless the error is resolved. The user must replace
the faulty part and restart the system. The setup POST error Pause setting does not
have any effect with this error.
Table 42. POST Error Messages and Handling
Error Code Error Message Response
0012 CMOS date / time not set Major
0048 Password check failed Major
0108 Keyboard component encountered a locked error. Minor
0109 Keyboard component encountered a stuck key error. Minor
0113
Fixed Media The SAS RAID firmware can not run properly. The user should
attempt to reflash the firmware.
Major
0140 PCI component encountered a PERR error. Major
0141 PCI resource conflict Major
0146 PCI out of resources error Major
0192 L3 cache size mismatch Fatal
0194 CPUID, processor family are different Fatal
0195 Front side bus mismatch Major
0196 Processor Model mismatch Major
0197 Processor speeds mismatched Major
0198 Processor family is unsupported. Major
019F Processor and chipset stepping configuration is unsupported. Major
5220 CMOS/NVRAM Configuration Cleared Major
5221 Passwords cleared by jumper Major
5224 Password clear Jumper is Set. Major
