Symbol Parameter Conditions Min Max Unit
3.3-V low-level
output voltage
V
CC(TRGT)
= 3.6 V, I
OL
= 1 mA — 0.125 V
2.5-V low-level
output voltage
V
CC(TRGT)
= 2.625 V, I
OL
= 1 mA — 0.125 V
1.8-V low-level
output voltage
V
CC(TRGT)
= 1.89 V, I
OL
= 1 mA — 0.125 V
1.5-V low-level
output voltage
V
CC(TRGT)
= 1.57 V, I
OL
= 1 mA — 0.125 V
I
CC(TRGT)
Operating current
(No Load)
Typical I
CC(TRGT)
= 16 uA — 100 uA
Table 7. DC Operating Conditions for USB Download Cable Rev. C
Symbol Parameter Conditions Min Max Unit
V
IH
High-level input
voltage
V
CC(TRGT)
>= 2.0 V 2.0 — V
V
CC(TRGT)
< 2.0 V V
CC(TRGT)
— V
V
IL
Low-level input
voltage
V
CC(TRGT)
>= 2.0 V — 0.8 V
V
CC(TRGT)
< 2.0 V — 0 V
V
OH
5.0-V high-level
output voltage
V
CC(TRGT)
= 4.5 V, I
OH
= -10 mA 3.8 — V
3.3-V high-level
output voltage
V
CC(TRGT)
= 3.0 V, I
OH
= -8 mA 2.3 — V
2.5-V high-level
output voltage
V
CC(TRGT)
= 2.375 V, I
OH
= -6 mA 1.8 — V
1.8-V high-level
output voltage
V
CC(TRGT)
= 1.71 V, I
OH
= -4 mA 1.2 — V
V
OL
5.0-V high-level
output voltage
V
CC(TRGT)
= 5.5 V, I
OL
= 10 mA — 0.8
3.3-V high-level
output voltage
V
CC(TRGT)
= 3.6 V, I
OL
= 8 mA — 0.7
2.5-V high-level
output voltage
V
CC(TRGT)
= 2.625 V, I
OL
= 6 mA — 0.6
1.8-V high-level
output voltage
V
CC(TRGT)
= 1.89 V, I
OL
= 4 mA — 0.5
I
CC(TRGT)
Operating current
(No Load)
Typical I
CC(TRGT)
= 16 uA — 100 uA
2.5 Power Requirements
The USB Download Cable V
CC(TRGT)
pin must be connected to a specific voltage for the
device being programmed. Connect pull-up resistors to the same power supply as the
USB Download Cable V
CC(TRGT)
.
2 Specifications for USB Download Cable
Intel FPGA USB Download Cable User Guide
7
