1 Product Description
1.1 Overview
1.1.1 Feature Summary
Table 1 summarizes the major features of Intel Desktop Board D2500HN.
Table 2. Feature Summary
Form Factor Mini-ITX, (6.7 inches by 6.7 inches [170 millimeters by 170 millimeters])
compatible with microATX
Processor Passively-cooled, soldered-down Dual-Core Intel
®
Atom™ processor with
integrated graphics and integrated memory controller
Memory
• Two 204-pin DDR3 SDRAM Small Outline Dual Inline Memory Module
(SO DIMM) sockets
• Support for DDR3 1066 MHz, DDR3 1333 MHz, and DDR3 1600 MHz
SO DIMMs
Note: DDR3 1333 MHz and DDR3 1600 MHz memory will run at 1066 MHz
• Support for up to 4 GB of system memory on a single SO-DIMM
Chipset Passively cooled, Intel
®
NM10 Express Chipset
Audio Multi-streaming 5.1 (6-channel) audio subsystem support based on the Realtek*
ALC662 high definition audio codec
Internal Graphics Onboard Intel
®
graphics subsystem with support for analog displays (VGA)
Legacy I/O Control Winbond W83627DHG-P based Legacy I/O controller for hardware management,
serial, parallel, and PS/2* ports
Peripheral
Interfaces
• Seven USB 2.0 ports:
― Four back panel ports
― Four ports are implemented with two dual port internal header for front
panel cabling
• Two Serial ATA (SATA) 3.0 Gb/s connectors (supporting IDE and AHCI mode)
• One parallel port connector on the back panel
• One serial port connector on the back panel
• One serial port header
• PS/2-style keyboard/mouse port
LAN Support 10/100/1000 Mb/s Ethernet LAN subsystem using an Intel
®
82574L Gigabit
Ethernet Controller
continued
