Product Description
33
1.11.2.3 Instantly Available PC Technology
Instantly Available PC technology enables the board to enter the ACPI S3 (Suspend-to-
RAM) sleep-state. While in the S3 sleep-state, the computer will appear to be off (the
hard drive(s) and fan will power off, the front panel LED will blink). When signaled by
a wake-up device or event, the system quickly returns to its last known state. Table 8
on page 31 lists the devices and events that can wake the computer from the S3 state.
The board supports the PCI Bus Power Management Interface Specification. Add-in
boards that also support this specification can participate in power management and
can be used to wake the computer.
1.11.2.4 Wake from USB
USB bus activity wakes the computer from an ACPI S3 state.
NOTE
Wake from USB requires the use of a USB peripheral that supports Wake from USB and
support in the operating system.
1.11.2.5 PME# Signal Wake-up Support
When the PME# signal on the PCI bus is asserted, the computer wakes from an ACPI
S3, S4, or S5 state (with Wake on PME enabled in the BIOS).
1.11.2.6 Wake from PS/2 Devices
PS/2 keyboard activity wakes the computer from an ACPI S3, S4, or S5 state.
However, when the computer is in an ACPI S4 or S5 state, the only PS/2 activity that
will wake the computer is the Alt + Print Screen or the Power Key available only on
some keyboards.
1.11.2.7 Wake from Serial Port
Serial Port activity wakes the computer from an ACPI S3 state.
