Intel Desktop Board D2500HN Technical Product Specification
18
1.4 System Memory
The board has two 204-pin DDR3 SO-DIMM sockets and supports the following
memory features:
• DDR3 SDRAM SO-DIMMs with gold-plated contacts
• Unbuffered, single-sided or double-sided DIMMs
• 4 GB maximum total system memory
• Minimum total system memory: 256 MB
• Non-ECC DIMMs
• Serial Presence Detect
• DDR3 1066 MHz, DDR3 1333 MHz, and DDR3 1600 MHz SO-DIMMs
(DDR3 1333 MHz and DDR3 1600 MHz memory will run at 1066 MHz)
NOTES
• Due to passively-cooled thermal constraints, system memory must have an
operating temperature rating of 85
o
C.
The board is designed to be passively cooled in a properly ventilated chassis.
Chassis venting locations are recommended above the system memory area for
maximum heat dissipation effectiveness.
• If you are installing only one SO-DIMM, it must be installed in the bottom socket
(SO-DIMM 1).
• To be fully compliant with all applicable DDR3 SDRAM memory specifications, the
board should be populated with SO-DIMMs that support the Serial Presence Detect
(SPD) data structure. This allows the BIOS to read the SPD data and program the
chipset to accurately configure memory settings for optimum performance. If non-
SPD memory is installed, performance and reliability may be impacted or the SO-
DIMMs may not function under the determined frequency.
Table 3 lists the supported SO-DIMM configurations.
Table 4. Supported Memory Configurations
1
Raw Card
Version
SO-DIMM
Capacity
DRAM Device
Technology
DRAM
Organization
# of DRAM
Devices
B
1 GB 1 Gb 128 M x 8 8
2 GB 2 Gb 256 M x 8 8
F
2 GB 1 Gb 128 M x 8 16
4 GB
2
2 Gb 256 M x 8 16
Notes:
1. System memory configurations are based on availability and are subject to change.
2. Support for one 4 GB SO-DIMM installed in slot 1. Slot 0 must be left empty.
