Intel Desktop Board D2500HN Technical Product Specification
42
Table 10 lists the component-side connectors and headers identified in Figure 11.
Table 11. Component-side Connectors and Headers Shown in Figure 11
Item/callout
from Figure 11 Description
A Processor core power connector (2 x 12)
B SATA connector
C SATA connector
D System fan header
E Front panel header
F Front panel USB 2.0 header
G Piezo/monotonic speaker header
H Conventional PCI bus add-in card connector
I S/PDIF header
J Front panel audio header
K Front panel USB 2.0 header
L Serial port header, COM 1
