► PEG Port Configuration
Press [Enter] to make settings for the following sub-items:
PEG Port Configuration
PEG (PCIE1 Slot)
Max Link Speed
Use this item to configure PED 0:1:0 Max Speed.
The optional settings: [Auto]; [Gen1]; [Gen2]; [Gen3].
Program PCIe ASPM after OpROM
The optional settings: [Disabled]; [Enabled].
[Enabled]: PCIe ASPM will be programmed after OpROM.
[Disabled]: PCIe ASPM will be programmed before OpROM.
► Memory Configuration
Press [Enter] to view brief information for the working memory module.
► PCH-IO Configuration
Press [Enter] to make settings for the following sub-items:
USB Controller
Use this item to enable or disable this USB Physical Connector (physical port).
Once disabled, any USB devices plug into the connector will not be detected by
BIOS or OS.
The optional settings: [Disabled]; [Enabled].
HD Audio
Use this item to control Detection of the HD-Audio device.
The optional settings: [Disabled]; [Enabled]; [Auto].
[Disabled]: HDA will be unconditionally disabled.
[Enabled]: HAD will be unconditionally enabled.
[Auto]: HAD will be enabled if present, disabled otherwise.
Onboard Lan1 Controller
Use this item to enable or disable onboard NIC.
The optional settings: [Enabled]; [Disabled].
When set as [Enabled], the following sub-items shall appear:
To Next Page
