Single Port QSFP+ Adapters
Label Indication Meaning
ACT/LNK
Green Linked at 40Gb
Yellow Linked at 1/10Gb
Blinking On/OFF Actively transmitting or receiving data
Off No link.
The Intel® Ethernet Converged Network Adapter XL710-Q1 has the following indicator lights:
Label Indication Meaning
ACT/LNK
Green Linked at 10Gb
Yellow
Linked at 1Gb
Blinking On/OFF Actively transmitting or receiving data
Off No link.
The Intel® Ethernet Converged Network Adapter X520-Q1 has the following indicator lights:
