143 Datasheet
Processor Pin and Signal Information
DMI_TX[3] J11 DMI O
DMI_TX#[0] H17 DMI O
DMI_TX#[1] K15 DMI O
DMI_TX#[2] J13 DMI O
DMI_TX#[3] F10 DMI O
DPLL_REF_SSCLK Y2 DIFF
CLK
I
DPLL_REF_SSCLK# W4 DIFF
CLK
I
FDI_FSYNC[0] AC7 CMOS I
FDI_FSYNC[1] AC9 CMOS I
FDI_INT AB5 CMOS I
FDI_LSYNC[0] AA1 CMOS I
FDI_LSYNC[1] AB2 CMOS I
FDI_TX[0] K1 FDI O
FDI_TX[1] N5 FDI O
FDI_TX[2] N2 FDI O
FDI_TX[3] R2 FDI O
FDI_TX[4] N9 FDI O
FDI_TX[5] R8 FDI O
FDI_TX[6] U6 FDI O
FDI_TX[7] W10 FDI O
FDI_TX#[0] L2 FDI O
FDI_TX#[1] N7 FDI O
FDI_TX#[2] M4 FDI O
FDI_TX#[3] P1 FDI O
FDI_TX#[4] N10 FDI O
FDI_TX#[5] R7 FDI O
FDI_TX#[6] U7 FDI O
FDI_TX#[7] W8 FDI O
GFX_DPRSLPVR AL71 CMOS O
GFX_IMON AL69 CMOS O
GFX_VID[0] AF71 CMOS O
GFX_VID[1] AG67 CMOS O
GFX_VID[2] AG70 CMOS O
GFX_VID[3] AH71 CMOS O
Table 8-50.BGA1288 Processor Ball
List by Ball Name
(Sheet 3 of 37)
Pin Name Pin #
Buffer
Type
Dir
GFX_VID[4] AN71 CMOS O
GFX_VID[5] AM67 CMOS O
GFX_VID[6] AM70 CMOS O
GFX_VR_EN AH69 CMOS O
ISENSE A41 Analog I
PECI N19 Async I/O
PEG_CLK L21 Diff CLK I
PEG_CLK# J21 DIFF
CLK
I
PEG_ICOMPI B12 Analog I
PEG_ICOMPO A13 Analog I
PEG_RBIAS B11 Analog I
PEG_RCOMPO D12 Analog I
PEG_RX[0] F40 PCIe I
PEG_RX[1] J38 PCIe I
PEG_RX[2] G34 PCIe I
PEG_RX[3] M34 PCIe I
PEG_RX[4] J28 PCIe I
PEG_RX[5] G25 PCIe I
PEG_RX[6] K24 PCIe I
PEG_RX[7] B28 PCIe I
PEG_RX[8] A27 PCIe I
PEG_RX[9] B25 PCIe I
PEG_RX[10] A24 PCIe I
PEG_RX[11] B21 PCIe I
PEG_RX[12] B19 PCIe I
PEG_RX[13] B18 PCIe I
PEG_RX[14] B16 PCIe I
PEG_RX[15] D15 PCIe I
PEG_RX#[0] G40 PCIe I
PEG_RX#[1] G38 PCIe I
PEG_RX#[2] H34 PCIe I
PEG_RX#[3] P34 PCIe I
PEG_RX#[4] G28 PCIe I
PEG_RX#[5] H25 PCIe I
PEG_RX#[6] H24 PCIe I
Table 8-50.BGA1288 Processor Ball
List by Ball Name
(Sheet 4 of 37)
Pin Name Pin #
Buffer
Type
Dir
