Intel P4000 - DATASHEET REV 001 - Page 87

Datasheet 87
Electrical Specifications
00 0 0 1 1 11.4125
00 0 1 0 0 01.4000
00 0 1 0 0 11.3875
00 0 1 0 1 01.3750
00 0 1 0 1 11.3625
00 0 1 1 0 01.3500
00 0 1 1 0 11.3375
00 0 1 1 1 01.3250
00 0 1 1 1 11.3125
00 1 0 0 0 01.3000
00 1 0 0 0 11.2875
00 1 0 0 1 01.2750
00 1 0 0 1 11.2625
00 1 0 1 0 01.2500
00 1 0 1 0 11.2375
00 1 0 1 1 01.2250
00 1 0 1 1 11.2125
00 1 1 0 0 01.2000
00 1 1 0 0 11.1875
00 1 1 0 1 01.1750
00 1 1 0 1 11.1625
00 1 1 1 0 01.1500
00 1 1 1 0 11.1375
00 1 1 1 1 01.1250
00 1 1 1 1 11.1125
01 0 0 0 0 01.1000
01 0 0 0 0 11.0875
01 0 0 0 1 01.0750
01 0 0 0 1 11.0625
01 0 0 1 0 01.0500
01 0 0 1 0 11.0375
01 0 0 1 1 01.0250
01 0 0 1 1 11.0125
01 0 1 0 0 01.0000
01 0 1 0 0 10.9875
01 0 1 0 1 00.9750
01 0 1 0 1 10.9625
01 0 1 1 0 00.9500
01 0 1 1 0 10.9375
01 0 1 1 1 00.9250
01 0 1 1 1 10.9125
01 1 0 0 0 00.9000
01 1 0 0 0 10.8875
01 1 0 0 1 00.8750
01 1 0 0 1 10.8625
01 1 0 1 0 00.8500
Table 7-35.Voltage Identification Definition (Sheet 2 of 4)
VID6 VID5 VID4 VID3 VID2 VID1 VID0 V
CC
(V)
