6
Jumpers
Jumper Name Description Page
JBAT CMOS RAM Clear 3-pin Block P.7
JP2 Keyboard and USB Power On Enabled/Disabled 3-pin Block P.8
JP3 USB Power On Enabled/Disabled 3-pin Block P.8
Connectors
Connector Name Description Page
ATXPWR ATX Power Connector 24-pin Block P.22
ATX12V ATX 12V Power Connector 8-pin Block P.23
J1 CrossFire Power Connector 4-pin Block P.23
KB PS/2 Mouse & PS/2 Keyboard Connector 6-pin Female P.23
USB fromUSB1,UL1 USB 2.0 Port Connector 4-pin Connector P.23
RJ45 LAN from UL1 RJ45 LAN Port Over USB Connector. 8-pin Connector P.23
AUDIO 8-CH Audio Connector 6 phone jack
Connector
P.23
FLOPPY Floppy Driver Connector 34-pin Block P.24
SATA1～SATA6 Serial ATA2 Connector 7-pin Connector P.24
COM1 Serial Port Connector 9-pin Connector P.24
SPDIF_ Out 2 Optical SPDIF Out Connector 1phone connector P.24
Headers
Header Name Description Page
FP_AUDIO SPEAKER, MIC header 9-pin Block P.25
USB2, USB3/USB4 Front Panel USB Port Headers 9-pin Block P.25
SPEAK PC Speaker header 4-pin Block P.25
PWR LED Power LED header 3-pin Block P.25
JW
_
FP(PW LED/Reset/
HD LED/PWR BTN)
Front Panel Header
(including Power LED/ IDE activity
LED/Reset switch / Power On Button led)
9-pin Block P.25
CPUFAN CPUFAN Headers 4-pin Block P.26
SYSFAN1, SYSFAN32 System FAN Headers 3-pin Block P.26
CDIN CD Audio-In Header 4-pin Block P.26
IR IR Header 5-pin Block P.26
Parallel Parallel Header 25-pin Block P.27
HDMI-SPDIF SPDIF-Out header 2-pin Block P.27
WI-FI Wi-Fi Header 11-pin Block P.27
Expansion Sockets
Socket/Slot Name Description Page
LGA 775 Socket CPU Socket LGA 775 CPU Socket
P.9
DIMM 1，2，3, 4
DDR2 Module Sockets 240-pin DDR2 Module Sockets
P.19
PCI1∼ PCI2
PCI Slots 32-bit PCI Local Bus Expansion slots
P.21
PE1 PCI-Express2.0 x16 Slot PCI-Express2.0 x16 Expansion Slot
P.21
PE2, PE3 PCI-Express1.0a x1 Slots PCI-Express1.0a x1 Expansion Slots
P.21
PE4 PCI-Express1.0a x16 Slot PCI-Express1.0a x16 Expansion Slot
P.21
