1-2 Specification
Spec Description
Design
∗ ATX form factor 4 layers PCB size: 30.5x22.0cm
Chipset
∗ Intel P43 Express Chipset
∗ Intel ICH10 chipset
CPU Socket
LGA775
∗ Support 45nm and 65nm Quad-Core, Dual-Core Intel® Core 2 Quad,
Core 2 Duo processors, Intel® Pentium Dual Core, Intel® Celeron Dual
Core Conroe processors and Intel® Celeron 400 Conroe-L processors
775-Land LGA Package utilizes Flip-Chip Land Grid Array (FCLGA)
package processor
∗ Support FSB Frequency 800/1066/1333MHz
Memory
Socket
∗ DDR2 Module socket x 4
∗ Support 4 pcs DDR2 667 /DDR2 800MHz DDR2 modules expandable
to 16GB
∗ Support Dual channel function
Expansion
Slot
∗ PCI-Express x16 slot 2pcs
∗ PCI-Express x1 slot 2pcs
∗ 32-bit PCI slot x 2pcs
Integrated
Serial ATA2
∗ The Intel ICH10 supports six Serial ATA ports provide 3.0 Gb/sec data
transfer rate.
Gigabit LAN
∗ Integrated Realtek RTL8111C PCI Gigabit LAN function.
∗ Supports Fast Ethernet LAN function provide 10Mb/100Mb/ 1Gb /s
data transfer rate.
8CH-Audio
∗ Realtek ALC883 8-channel HD Audio Codec integrated
∗ Support 8-channel 3D surround & Positioning Audio
∗ Audio driver and utility included
BIOS
∗ Award 8MB SPI Flash ROM
Multi I/O
∗ PS/2 keyboard and PS/2 mouse connectors
∗ Floppy disk drive connector x1
∗ SATA Connector x6
∗ SPDIF_OUT connector x1
∗ HDMI_SPDIF header x1/IR header
∗ USB2.0 port x 4 and headers x3
∗ RJ-45 LAN connector x1
∗ Serial port connector x1
∗ Parallel header x1
∗ WI-FI header x1
∗ Audio connectorx1 (8-CH Audio)
