3-10 PC Health Status
This section shows the Status of you CPU, Fan, and Warning for overall system status. This
is only available if there is Hardware Monitor onboard.
Phoenix – AwardBIOS CMOS Setup Utility
PC Health Status
Item Help
Shutdown Temperature Disabled
CPU Thermal-Throttling Disabled
* CPU Throttling Temp 70
* CPU Thermal-Throttling Duty 50.00%
* CPU Thermal –Throttling Beep Enabled
Show PC Health in POST Enabled
> Smart FAN Configurations Press Enter
VCC3v 3.31V
Vcore 1.28V
NB Core 1.26V
+5V 5.12V
+12V 11.88V
5VSB 5.00V
DRAM Voltage 1.87V
3VSB 3.37V
Vbat 3.28V
CPU Temperature 64°C147°F
System Temperature 38°C/96°F
CPUFAN Speed 2912RPM
SYSFAN1 Speed 5836 RPM
SYSFAN2 Speed 0 RPM
Menu Level >
↑↓→← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Optimized Defaults F7:Standard Defaults
Shutdown Temperature
This item can let users setting the Shutdown temperature, when CPU temperature over this
setting the system will auto shutdown to protect CPU.
Show PC Health in Post
During Enabled, it displays information list below. The choice is either Enabled or Disabled.
CPU Temperature/ System Temperature/CPU FAN Speed, SYS FAN1, SYSFAN2
Speed/VCC 3V/Vcore/ NBCore/+5V/+12V/5VSB(V)/DRAM Voltage/3VSB/Vbat
This will show the CPU/FAN/System voltage chart and FAN Speed.
CPU Thermal Throttling Temp
This item is for users to activate CPU Thermal Throttling function. When CPU is in high
temperature and with high workload, system will automatically force CPU to enter idle mold
so as to avoid damage to CPU.
