Intel P43 User Manual

33
During POST, BIOS will determine if the floppy disk drive installed is 40 or 80 tracks.
360K type is 40 tracks while 760K, 1.2M and 1.44M are all 80 tracks.
Boot Up NumLock Status
The default value is On.
On
(default) Keypad is numeric keys.
Off
Keypad is arrow keys.
Security Option
This category allows you to limit access to the system and Setup, or just to Setup.
System
The system will not boot and access to Setup will be denied if the
correct password is not entered at the prompt.
Setup
(default) The system will boot, but access to Setup will be denied if the correct
password is not entered prompt.
MPS Version Control For OS 1.4
This option is only valid for multiprocessor motherboards as it specifies the version of the
Multiprocessor Specification (MPS) that the motherboard will use.
OS Select For DRAM > 64MB
Allows OS2
®
to be used with >64MB or DRAM. Settings are Non-OS/2 (default) and OS2.
Set to OS/2 if using more than 64MB and running OS/2
®
.
HDD S.M.A.R.T Capability
The settings are: Disabled and Enabled.
3-6 Advanced Chipset Features
The Advanced Chipset Features Setup option is used to change the values of the chipset
registers. These registers control most of the system options in the computer.
Phoenix – AwardBIOS CMOS Setup Utility
Advanced Chipset Features
Item Help
DRAM Timing Selectable By SPD
*DRAM CAS Latency Time Auto
*DRAM RAS# TO CAS# Delay Auto
*DRAM RAS# Precharge Time Auto
*DRAM Cycle Tiem Auto
*DRAM Write Recovery Time Auto
*DRAM Min Ref to Act/CMD Time Auto
*DRAM Int Wrt to Rd Delay Auto
*DRAM Row Act to Row Act Delay Auto
*DRAM Int Rd to Pre Delay Auto
System BIOS Cacheable Disabled
Memory Hole at 15-16M Disabled
PCI Express Root Port Function Press Enter
Force PEG to x1 Disabled
Menu Level >
↑↓→← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Optimized Defaults F7:Standard Defaults
System BIOS Cacheable
