Intel P43 User Manual

40
3-11 Miscellaneous Control
Phoenix – AwardBIOS CMOS Setup Utility
Miscellaneous Control
Item Help
CPU Clock Ratio 10X
Auto Detect PCI Clock Enabled
Spread Spectrum Disabled
CPU Diff AMP Control 800mv
CPU CLK SKEW Control 0ps
NB CLK Skew Control 0ps
Linear PCIEX Clock 100MHz
** Current Host/PCI Clock 200/33MHZ**
Host/PCI Clock at Next Boot 200/33MHZ
** Current DRAM Clock is 800 MHz **
DRAM Clock at Next Boot Auto/800MHz
CPU PLL Select 1.500v(Default)
SB core Select 1.500v(Default)
CPU VTT Select Default
NB Core Select 1.125v(Default)
DRAM Voltage Select 1.850(Default)
CPU Vcore X-Shift +0.00V(Default)
Menu Level >
↑↓→← Move Enter:Select Item +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Optimized Defaults F7:Standard Defaults
CPU PLL Select
The optional settings are from 1.500V(Default)to 3.031V.
CPU VTT Select
The optional settings are from +1.91% to 120.09%.
DRAM Voltage Select
This item allows you to set DRAM voltage. Motherboards based on different chipset series
have different voltage range.
Host/PCI Clock at Next Boot
This item allows user to set CPU/PCI clock frequency.
NB Core Select
This item allows you to select value of Voltage for North Bridge Chipset. Motherboards
based on different chipset series have different setting range.
CPU Diff AMP Control
The optional settings are： 700mV;800mV;900mV and 1000mV.
Linear PCIE X Clock
This item allows you to set Linear PCI Ex clock fraquency. Motherboards based on different
chipset series have different setting range.
DRAM Clock at Next Boot
This item allows you to set DRAM clock frequency.
CPU Vcore7-Shift
This item allows you to over-clock precisely in the preset range from -0.40V to +0.63V.
SB Core Select
This item allows you to select value of Voltage for South Bridge Chipset.
