15
SPEAK1
SPEAK
NC
NC
VCC
Pin 1
PWRLED1
Pin 1
VCC
GND
GND
(5) Front Panel Header: JW-FP
HDLED
RESET
VCC5
GND
VCC5
PWR LED
PWRBTN
PWRBTN
PWRLED
HDDLE
RSTSW
NC
GND
JW FP
Pin 1
(6) USB Port Headers (4-pin): USB1/USB2/USB3
Pin 1
USB1
VCC
-DATA
GND
+DATA
VCC
O
C
-DATA
GND
+DATA

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Intel Q67 and is the answer not in the manual?

Intel Q67 Specifications

General IconGeneral
ChipsetIntel Q67
SocketLGA 1155
Memory TypeDDR3
Max Memory32 GB
PCI Express Revision2.0
Memory Slots4
Memory SupportDDR3 1066/1333 MHz
USB Ports14
SATA Ports6
Integrated GraphicsYes
RAID SupportRAID 0, 1, 5, 10
CPU Support2nd Generation Intel Core i7/i5/i3 Processors
