Intel Q77 User Manual

37
Use this item to enable or diable integrated LAN to wake the system.
Onboard Lan2 Device
Use this item to control the PCI Express root port.
DeepSx Power Policies
Use this item to configure the Deep Sx Mode configuration.
High Precision Event Timer Configuration
High Precision Timer
The optional settings are: [Enabled]; [Disabled].
Restore AC Power Loss
Use this item to select AC power state when power is re-applied after a power
failure. The optional settings are: [Power Off]; [Power On]; [Last State].
► System Agent (SA) Configuration
Press [Enter] to make settings for the following sub-items:
Enable NB Card
The optional settings are: [Enabled]; [Disabled].
► Graphics Configuration
Press [Enter] to make further settings for Graphics Configuration.
Graphics Configuration
Primary Display
The optional settings are: [Auto]; [IGFX]; [PEG]; [PCI].
Internal Graphics
The optional settings are: [Auto]; [Disabled]; [Enabled].
CTT Size
The optional settings are: [1MB]; [2MB].
Aperture Size
The optional settings are: [128MB]; [256MB]; [512MB].
DVMT Pre-Allocated
Use this item to select DVMT 5.0 pre-allocated (fixed) graphics memory size used
by the internal graphics device.
DVMT Total Gfx Mem
Use this item to select DVMT 5.0 total graphics memory size used by the internal
graphics device.
GFx Low Power Mode
The optional settings are: [Disabled]; [Enabled].This option is applicable for SFF

Intel Q77 Specifications

General

Chipset	Intel Q77
Socket Type	LGA 1155
Memory Type	DDR3
Memory Slots	4
Maximum Memory Supported	32 GB
SATA 3Gb/s Ports	4
SATA 6Gb/s Ports	2
USB 2.0 Ports	10
USB 3.0 Ports	4
PCI Express Revision	3.0
Integrated Graphics	Intel HD Graphics
PCIe 3.0 Support	Yes
CPU Support	Intel Core i7/i5/i3, Pentium, Celeron (2nd and 3rd generation)
Memory Support	DDR3 1066/1333/1600 MHz
RAID Support	RAID 0, 1, 5, 10
TDP	Not Applicable
