Intel Q77 User Manual

38
only.
LCD Control
Primary IGFX Boot Display
The optional settings are [VBIOS default]; [CRT]; [HDMI]; [LVDS].
Secondary IGFX Boot Display
The optional settings are [Disabled]; [CRT]; [HDMI]; [LVDS].
* Note: The above item shall appear when Primary IGFX Boot Display set as
[CRT], [HDMI] or [LVDS].
Active LFP
The optional settings are: [Disabled]; [Enabled].
► North PCIe Configuration
Press [Enter] to make settings for the following sub-items:
NB PCIe Configuration:
PEG0-Gen X
The optional settings are: [Auto]; [Gen1]; [Gen2]; [Gen3].
PEG0 ASPM
The optional settings are: [Disabled]; [Auto]; [ASPM L0s]; [ASPM L1]; [ASPM
L0sL1].
Enable PEG
The optional settings are: [Auto];[Enabled]; [Disabled].
De-emphasis Control
The optional settings are: [-6 dB]; [-3.5 dB].
► Memory Configuration
Press [Enter] to make settings for the following sub-items:
DIMM profile
Use this item to select DIMM timing profile that should be used.
Memory Frequency Limiter
Use this item to set maximum memory frequency selection in Mhz.
MMode Support
The optional settings are: [Auto]; [1N Mode]; [2N Mode].
Memory Remap
Use this item to enable or disable memory remap above 4G. The optional settings
are: [Enabled]; [Disabled].

Intel Q77 Specifications

General

Chipset	Intel Q77
Socket Type	LGA 1155
Memory Type	DDR3
Memory Slots	4
Maximum Memory Supported	32 GB
SATA 3Gb/s Ports	4
SATA 6Gb/s Ports	2
USB 2.0 Ports	10
USB 3.0 Ports	4
PCI Express Revision	3.0
Integrated Graphics	Intel HD Graphics
PCIe 3.0 Support	Yes
CPU Support	Intel Core i7/i5/i3, Pentium, Celeron (2nd and 3rd generation)
Memory Support	DDR3 1066/1333/1600 MHz
RAID Support	RAID 0, 1, 5, 10
TDP	Not Applicable
