24 Intel® Server Board S3420GPRX User Guide
5. Locate the processor socket and open the socket lever (see Figure 11).
Figure 11. Lifting the Load Lever
6. Open the load plate (see letter “A” and “B” in Figure 12).
Figure 12. Open the Load Plate
REMOVE
AF003186
A
B
REMOVE
AF003187
REMOVE
A
B
