Intel Solid-State Drive 320 Series User Manual

Intel
®
Solid-State Drive 320 Series
September 2011 Product Specification
Order Number: 325152-002US 13
Intel
®
Solid-State Drive 320 Series
4.0 Pin and Signal Descriptions
4.1 Pin Locations
4.1.1 1.8-inch Form Factor Pin Locations
4.1.2 2.5-inch Form Factor Pin Locations
Note: 2.5-inch connector supports in-built latching capability.
Figure 4. Layout of Signal and Power Segment Pins
Figure 5. Layout of Signal and Power Segment Pins
Signal Segment S1 Power Segment P1
Signal Segment S1 Power Segment P1

Intel Solid-State Drive 320 Series Specifications

General

Brand	Intel
Model	Solid-State Drive 320 Series
Category	Storage
Language	English
