Intel X550-T2 User Manual

Before beginning the configuration, update the adapter's UEFI FCoE Option ROM using the BootUtil tool and
the latest BootIMG.FLB file. Use the following command:
BOOTUTIL64E.EFI -up=efi+efcoe -nic=PORT -quiet
where PORT is the NIC adapter number (in the following example nic=1)
NOTE: The UEFI FCoE driver must be loaded before you perform the following steps.
Accessing the FCoEConfiguration Screen
Boot the system into its BIOSand proceed as follows:
1. Select the Advanced tab, then choose PCIConfiguration, then UEFIOption ROM Control, then
FCOEConfiguration.
2. The following screen is displayed:
Adding an FCoEAttempt
An FCoE Attempt is a configured instance of a target from which the system will attempt to boot over FCoE.

Intel X550-T2 Specifications

General

Product Type	Network Adapter
Ports	2 x 10GBase-T
Interface	PCI Express 3.0 x4
Data Transfer Rate	10 Gbps
Connector Type	RJ-45
Form Factor	Plug-in Card
Chipset	Intel X550
Connectivity Technology	Wired
Operating Temperature	0°C to 55°C
Storage Temperature	-40°C to 70°C
Cabling Type	Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T, Ethernet 10GBase-T
Features	VLAN support, Wake on LAN (WoL), PXE support
Compliant Standards	IEEE 802.3an, IEEE 802.3az, IEEE 802.1Q, IEEE 802.3x
Jumbo Frames	9.5KB
