The dip-switches position 1 thru 5 are all preset to “ON” at the factory. Changing the setting of S1-1, S1-2, or S1-3 will
alter the order of shedding to suit the particular need of the installation. The tables below will assist in determining
the proper settings for S1-1 thru S1-3.
Next, looking across the other eight columns, find the one that matches the "Load Type" column you just filled in.
Using the number at the top of the column, look in the table below to determine the settings of the three switches, S1-
1, S1-2, and S1-3. An "ON" means the switch should be closed, and an "OFF" means the switch should be open.
The first step is to fill in the blanks with the names of the loads you want the system to shed, in the order they are to be
shed, with the first to be shed at the top. Then, fill in the second, "Load Type", column with an "A" or a "D", an "A" for a
120 VAC controlled load such as a washer/dryer, or a "D" for DC controlled load, such as a thermostat wire. You can
select a maximum of 3 AC\1 DC relays, or 2 AC\2 DC relays.
At the bottom of each column is the Relay Shed Order. This determines which relays will be used for each load. The
one at the top of the column is first to be shed. The one below it will turn off next and so forth. The loads be
wired in this order for the system to operate as desired.
Finally, the number and size of the circuit breakers should be selected to meet the needs of the installation. The
breakers can be either single, or dual types. One of these breakers MUST be a 30 Amp unit to act as the Main
breaker. The breakers must be obtained and then installed in the box.
RELAY WIRING TABLE
MUST
(See information on breaker types later in this
manual.)
LOAD NAME
(First to shed at top)
Load
Type
1 2 3 4 5 6 7 8
A A A A A A D D
A A A D D D A A
A D D A A D A D
D A D A D A D A
Column
Number
1 2 3 4 5 6 7 8
S1-1 ON
ON
ON
ON
ON OFF ON OFF
S1-2 ON ON OFF OFF ON ON OFF OFF
S1-3 ON
OFF
ON
OFF
OFF OFF OFF OFF
Relay
Shed
Order
1
2
3
6
1
2
6
3
1
2
5
6
1
5
2
3
1
5
2
6
1
5
6
3
5
2
3
6
5
2
6
3
