Intellitec 500A - Page 6

1485 Jacobs Rd.
Deland, FL 32724
386.738.7307
P/N 53-00912-000 Rev. D 080919
www.intellitec.com
Intellitec
INSTALLATION & SERVICE MANUAL
30A SMART ENERGY MANAGEMENT SYSTEM
TM
MODEL 500A
RELAY 1
J7 - RELAY 3
RELAY 2
J6-TERMINAL 5
5A 32V FUSE
CONFIGURATION
DIP-SWITCH
J5 - DISPLAY
CONNECTOR
J4 - LOW VOLTAGE
RELAY CONNECTOR
J2 - +12V POWER
CONNECTOR
J3 - TO CURRENT
TRANSDUCER
