Intense UZZI - Torque Specifications Chart; Torque Importance and Reference

torque
Achieving proper torque is vital to
ensuring the safe performance and
function of the uzzi frame. Failure
to do so could result in sub-optimal
performance of your frame as well as
premature wear and tear of individual
parts.
additional reference
In addition to this chart, all torque values
are laser etched onto corresponding
hardware for your reference.
14 // uzzi user Manual
torque chart
20 Nm / 175 in-lbs
7 Nm / 60 in-lbs
7 Nm / 60 in-lbs
20 Nm / 175 in-lbs
M8 HEX 7 Nm / 60 in-lbs
M5 HEX 14 Nm / 125 in-lbs
M8 HEX 7 Nm / 60 in-lbs
M5 HEX 14 Nm / 125 in-lbs
Derailleur Hanger: 11 Nm / 100 in-lbs
