Intense UZZI - Page 7

INTENSE CYCLES // 7
ITEM
NO.
ITEM
PART
NUMBER
DESCRIPTION QTY. TORQUE SPEC.
1
Top Link 130220 Machined Upper Link 1 N/A
2
Box Link 130764 Machined Lower Link 1 N/A
3
Cone Adjuster 130777 Expander Cone 2 N/A
4
Bearing Cap 130778 Box Link Bearing Cap 4 N/A
5
Axle Upper 130780 Top Link Pivot Axle 1
20 Nm /
175 in-lbs
6
Washer 130784 Top Link Pivot, Lower Washer 2 N/A
7
Bolt Shoulder 130785 Top Link Pivot Bolt, Upper Pivot 3
20 Nm /
175 in-lbs
8
Spacer 130789 Top Link Pivot, Upper Spacer 2 N/A
9
Hanger 130790 Forged Derailleur Hanger 1 N/A
10
Bolt 130791 Main Pivot Bolt 2
7 Nm /
60 in-lbs
11
Hanger Bolt 130792 Rear Derailleur Hanger Bolt 1
11 Nm /
100 in-lbs
12
Rear Axle 130799 148 x 12mm Boost 1
11 Nm /
100 in-lbs
13
Plug 140004 Box Link Pivot Plug 2 N/A
14
Bumper 140006 Box Link Bumper 1 N/A
15
Clip 310001 Cable Guide Clip 11 N/A
16
Cable Guide 310005 Seat Post Cable Guide 1 N/A
17
Seat Collar 346941 Bolt-On 36.0 1 N/A
18
Nut 400009 Shock Bolt Nut, M6 x 1.0 x 2mm 2 N/A
19
Zerk Fitting 401011 M6 x 1.0 Thread 2
5 Nm /
40 in-lbs
20
SHCS M6 x 40 410002
Front Shock Bolt, Socket Head,
M6 x 40
1
7 Nm /
60 in-lbs
21
SHCS M6 x 22 410009
Cone Adjuster Bolt, Socket
Head, M6 x 22
2
14 Nm /
125 in-lbs
ITEM
NO.
ITEM
PART
NUMBER
DESCRIPTION QTY. TORQUE SPEC.
22
SHCS M6 x 35 410049
Rear Shock Bolt, Socket Head,
M6 x 35
1
7 Nm / 60
in-lbs
23
Bearing 61901 430001 12 x 24 x 6 2RS Radial Bearing 2 N/A
24
Bearing 7902 430007
15 x 28 x 7 2RS MAX Angular
Contact Bearing
4 N/A
25
Bearing 6802 430008
15 x 24 x 5 2RS MAX Radial
Bearing
2 N/A
26
Decal California
Bear
500300 Decal California Bear 1 N/A
27
Head Badge 500335 Flame Logo 1 N/A
28
Rear Shock N/A 8.5” x 2.5” (216mm x 64mm) 1 N/A
29
Front Triangle
Uzzi Front
Triangle
Aluminum, 4 sizes 1 N/A
30
Rear Triangle
Uzzi Rear
Triangle
Aluminum, 1 size 1 N/A
