intensity IF COMBO DI4738 User Manual

TENSPros
Technical specifications for Transcutaneous Electrical Nerve
Stimulator (TENS) mode
Waveform Mono-phase square pulse wave
Pulse amplitude
Adjustable, 0~105mA peak at 1000
ohm Load each channel, 1mA/Step.
Pulse Width
Adjustable, from 50 to 300us
microseconds, 10μS/step
Pulse Rate
Adjustable, from 1 to 150 Hz, 1
Hz/step
Burst (P1)
Burst rate: Adjustable, 0.5 ~ 5Hz;
0.1Hz/step
Pulse width adjustable, 50~300μS
Frequency fixed = 100 Hz
Normal (P2)
The pulse rate and pulse width are
adjustable. It generates continuous
stimulation based on the setting
value.
Pulse Width Modulation
(P3)
The pulse width is automatically
varied in a cycle time. The pulse
width is decreased from its original
setting to 60% in setting cycle time,
and then increased from 60% to its
original setting in nest setting cycle
time. In this program, pulse rate (1
to 150Hz), pulse width (50 to 300us)
and cycle time (5 to 30 sec) are fully
adjustable.
Pulse Rate Modulation (P4)
The pulse rate is automatically
varied in a cycle time. The pulse rate
is decreased from its original setting
to 60% in setting cycle time, and
then increased from 60% to its
original setting in nest setting cycle
time. In this program, pulse rate (1
to 150Hz), pulse width (50 to 300us)
and cycle time (5 to 30 sec) are fully
adjustable.
13
