3. Specification
3.1 Accessories
No DESCRIPTION Q’TY
1 Electrical stimulator device 1 piece
2 Electrodes Leads 2 pieces
3 1.5” x 1.5” Adhesive Electrodes 4 pieces
4 9V Alkaline Battery, type 6LR61 1 piece
5 Instruction Manual 1 piece
6 Carrying case 1 piece
7 AC Adaptor (optional) 1 piece
3.2 Technical information
Channel Dual, isolated between channels
Power supply
9.0 V Alkaline DC -1 *6LR61 battery
Adapter output:9.0Vdc 800mA
Operating conditions
5°C to 40°C （41℉ to 104℉）with a
relative humidity of 30%-75%,atmospheric
pressure from 700 to 1060 Hpa
Storage conditions
-10°C to 50°C （14℉ to 122℉）with a
relative humidity of 10%-90%,atmospheric
pressure from 700 to 1060 Hpa
Dimensions 4.5×2.55×0.9 inches(L*W*H)
Weight 0.28 lbs(With battery)
Tolerance
There may be a ±5% tolerance of all setting
and ±10% tolerance of output of intensity.
Electrode Detection
Function
The amplitude level will be reset to 0mA
when the amplitude level is 12mA or greater
and an open circuit at either channel is
detected.
Timer
Adjustable, from 1 to 60 minutes or
continuous, Adjustable in 1minutes each
step. Treatment time countdown
automatically.
