I N S T A L L A T I O N M A N U A L X - S T R E A M 2 ™ S L I D E
19
XS2-IM Rev. 10/14 (SBK-XS2 INSTALL)
X-STREAM 2™ SLIDE (XS-GR-SS):
HARDWARE NOTE:
Use a small dab of
anti seize lubricant
(included) on all bolt
threads.
DRAWING REPRESENTS THE FOLLOWING PART NUMBERS:
XS-GR-SS
ALL CHART INFORMATION BELOW CORRESPONDS WITH THE DRAWING ON THE PREVIOUS PAGE.
<---
NOTES:
X-Stream 2 slide only comes in Summit Gray
X-Stream 2 can turn to the right or the left
ITEM # COMPONENT DESCRIPTION
XS-GR-SS
XS-101-SS
XS2-102-SS
XS-103-SS
XS-104-SS
XS2-105-SS
STEP
ASSEMBLY
HARDWARE KITS/PARTS KITS – QTY. COUNTS
1 XS-RIGHT FLUME A & B RIGHT HAND FLUME SECTION 1
2 XS-LEFT FLUME C & D LEFT HAND FLUME SECTION 1
3 XS-EXIT BOTTOM SECTION 1
4 XS-ENTRY TOP SIDE SECTION WITH WATER OUTLET 1
5 XS-L HANDRAIL LEFT HANDRAIL WITH X-STREAM LOGO 1
6 XS-R HANDRAIL RIGHT HANDRAIL WITH X-STREAM LOGO 1
7 XS-FOOT PEDESTAL STRAIGHT FOOT PEDESTAL 2
8 PEDESTAL 16 DEGREE FOOT PEDESTAL 1
9 H-6 X 21.250 6" X 21.250" GRAY PVC PIPE SCHEDULE 40 1
10 H-6 X 45.375 6" X 45.375" GRAY PVC PIPE SCHEDULE 40 1
11 H-6 X 71.5 6" X 71.5" GRAY PVC PIPE SCHEDULE 40 1
12 XS-STEP X-STREAM BLOW MOLDED STEP 5
13 H-.463 X .310 CAP GRAY PROTECTIVE CAP 4
14 H-.562 X .390 CAP GRAY PROTECTIVE CAP 8 25 6 13
15 H-SS 3/8 F NUT 3/8” FINISH NUT S.S. 15 6
16 H-SS 3/8 FLT WASHER 3/8” X 1” FLAT WASHER S.S. 16 25 12 13
17 H-SS 3/8 LOC WASHER 3/8” LOCK WASHER S.S. 15 6 13
18 H-SS 3/8 NYLON 3/8” NYLON INSERT NUT S.S. 8
19 H-SS 3/8 WEDGE 3/8” X 2-3/4” WEDGE ANCHOR W/NUT & FLAT WASHER S.S. 8
20 H-SS 3/8 X 3 TAP 3/8” X 3” HEX HEAD TAP BOLT S.S. 10
21 H-SS 3/8-16X2 3/8” X 2” HEX HEAD BOLT S.S. 8 12
22 H-SS 3/8X2-1/2 3/8” X 2-1/2” ALL-THREAD STUD S.S. 5
23 H-SS 5/16 FLA WASHER 5/16” FLAT WASHER S.S. 4
24 H-SS 5/16 HEX FLANGE 5/16” HEX FLANGE NUT S.S. 14
25 H-SS 5/16 X 2 5/16” X 2” ALL-THREAD STUD S.S. 10
26 H-SS 5/16 X 2-1/2 5/16” X 2-1/2” ALL-THREAD STUD S.S. 4
27 H-G4C GASKET U-SHAPED GASKET - 3 HOLES 3
28 H-1 BALL VALVE 1" BALL VALVE-SLIP GRAY 1*
29 H-NYLON ROD 101 NAT NYLON ROL 101 .375 DIA. 5*
30 H-1 SPA HOSE GRAY SPA HOSE FOR STEP ASSEMBLY, 10 FT. LENGTH 10*
31 XS2 WATER OUTLET COMES AS PART OF ENTRY SECTION 1*
32 XS-STEP COMP COMPLETE ASSEMBLED STEP, INCLUDES ITEMS 8, 11, 12, & 29 1
33 H-ANTI-SEIZE ANTI-SEIZE PACKET (NOT SHOWN)
34 H-SS 3/8 X 7-1/2 3/8” X 7-1/2” HEX HEAD BOLT 6
35 H-SS 3/8 X 3-1/2 W 3/8” X 3-1/2” WEDGE ANCHOR W/NUT & FLAT WASHER S.S. 5
36 H .531 X 1 GRAY .531” X 1” GRAY PROTECTIVE CAP 6
* not pictured
