I N S T A L L A T I O N M A N U A L X - S T R E A M 2 ™ S L I D E
20
XS2-IM Rev. 10/14 (SBK-XS2 INSTALL)
X-STREAM 2™ SLIDE HARDWARE KITS
XS-101-SS – PVC LEG TO FOOT RECEIVER
QTY PART NUMBER COMPONENT DESCRIPTION
8 H-SS 3/8-16X2 3/8” x 2” hex head bolt s.s.
8 H-SS 3/8 NYLON 3/8” nylon insert nut s.s.
1
6 H-SS 3/8 FLT WASHER 3/8” x 1” flat washer s.s.
8 H-.562 X .390 CAP gray protective cap
XS2-102-SS – FLUME HARDWARE
QTY PART NUMBER COMPONENT DESCRIPTION
5 H-SS 3/8X2-1/2 3/8” x 2-1/2” all-thread stud s.s.
15 H-SS 3/8 F NUT 3/8” finish nut s.s.
15 H-SS 3/8 LOC WASHER 3/8” lock washer s.s.
25 H-SS 3/8 FLT WASHER 3/8” x 1” flat washer s.s.
10 H-SS 3/8 X 3 TAP 3/8” x 3” hex head tap bolt s.s.
25 H-.562 X .390 CAP gray protective cap
XS-103-SS – PVC LEG TO FLUME
QTY PART NUMBER COMPONENT DESCRIPTION
6 H-SS 3/8 LOC WASHER 3/8” lock washer s.s.
12 H-SS 3/8 FLT WASHER 3/8” x 1” flat washer s.s.
12 H-.562 X .390 CAP gray protective cap
6 H-SS 3/8 X 7-1/2 3/8” x 7-1/2” hex head bolt
XS-104-SS – FOOT RECEIVER TO DECK
QTY PART NUMBER COMPONENT DESCRIPTION
13 H-SS 3/8 LOC WASHER 3/8” lock washer s.s.
8 H-SS 3/8 WEDGE 3/8” x 2-3/4” wedge anchor w/nut & flat washer s.s.
13 H-.562 X .390 CAP gray protective cap
5 H-SS 3/8 X 3-1/2 W 3/8” x 3-1/2”
wedge anchor w/nut & flat washer s.s.
XS2-105-SS – HANDRAIL HARDWARE
QTY PART NUMBER COMPONENT DESCRIPTION
10 H-SS 5/16 X 2 5/16” x 2” all-thread stud s.s.
4 H-SS 5/16 X 2-1/2 5/16” x 2-1/2” all-thread stud s.s.
4 H-SS 5/16 FLA WASHER 5/16” flat washer s.s.
14 H-SS 5/16 SER 5/16” hex flange nut s.s.
4 H-.463 X .310 CAP gray protective cap
