A-60/A-120 Public Address Amplifier
Specifications
ELECTRICAL
Rated Output/Impedance A-60: 15.5V/4; 70V/81.6; 100V/166.7
A-120: 21.9V/4; 70V/40.8; 100V/83.3
Input Sensitivity/Impedance
Mic Input 1-3 -60dB/600, Bal
Aux 1 Input -10dB/10k, Unbal
Aux 2 Input + 3dB/10k, Unbal
Frequency Response ( ±3dB) 80Hz–16kHz
T.H.D Less than 1%
S/N
Mic Better than 60dB
Aux Better than 75dB
Tone Control
Treble (10kHz) ±12dB
Bass (100Hz) ±12dB
GENERAL
Power Source AC 110V-240V, 50/60Hz
Power Consumption A-60: 75W
A-120: 105W
Weight A-60: 8.9 Kg (19.6 lbs)
A-120: 10.3 Kg (22.7 lbs.)
Dimensions 420(W) x 88(H) x 320(D) mm
16.5(W) x 3.5(H) x 12.6(D) inches
* Specifications and design subject to change without notice for improvements.
