Inter-m LM-8000 - Specifications

8X8 AUDIO MATRIX SYSTEM
21
PX-8000/RM-8000/LM-8000
Specifications
Specifications
................................................................................................................0dB=1Vrms
PX-8000 RM-8000 LM-8000
Audio Output 0dB(Balanced)
Audio Input Paging & RM MIC & LM MIC -50dB(Balanced)
BGM(Main & Local) -10dB(Balanced)
Tone Control Paging MIC 10dB
(100Hz & 10kHz)
Audio Output 12dB
Frequency Response BGM (60Hz ~ 15kHz) 3dB
MIC (100Hz ~ 10kHz) 3dB
S/N BGM Better than 75dB
MIC Better than 65dB
T.H.D. BGM Less than 0.05%
MIC Less than 0.05%
Priority Control Paging MIC > DRP > RM1 > RM2> RM3> RM4 > LM-8000 > Main BGM
Phantom Power DC 24V
Serial Interface Communication Speed
9600bps
(RS-422)
Communication Distance
Maximum 300m (UTP CAT5)
Operation Temperature
-10˚C ~ +40˚C
Power Source
100–120VAC or 220–240VAC; 50/60Hz
(Supplied AC mains transformer depends on country requirements)
Power Consumption 60W - -
Weight (SET) 7.5kg/16lb 1.5kg/3.2lb 130g/0.28lb
Dimensions (SET)
482(W)x132(H)x380(D)mm 200(W)x70(H)x206(D)mm 70(W)x114(H)x52(D)mm
19(W)x5.2(H)x15(D)in 7.9(W)x2.8(H)x8.1(D)in 2.8(W)x4.5(H)x2.0(D)in
* Specifications and design are subject to change without notice.
