PUBLIC ADDRESS AMPLIFIER
11
MA-206/212
MA-206 MA-212
Rated Output (RMS) 60W 120W
Frequency Response 80Hz-15kHz
Total Harmonic Distortion (T.H.D) Less than 1%
Signal to Noise Ratio
(S/N @ LINE IN)
Better than 75dB
Graphic Equalizer
±12dB
(100Hz, 330Hz, 1KHz, 3.3KHz, 10KHz)
INPUT SENSITIVITY/IMPEDANCE
INPUT 1~5
MIC -50dBV / 2kΩ
LINE -10dBV / 2kΩ
INPUT 6 -10dBV / 20kΩ
TEL IN 0.775dBV / 10kΩ
LINE IN 0dBV / 10kΩ
AMP IN 0dBV / 10kΩ
LINE OUTPUT/IMPEDANCE 0dBV / 600Ω
15.5V / 4Ω 22V / 4Ω
SPEAKER OUT / IMPEDANCE 70V / 82Ω 70V / 41Ω
100V / 167Ω 100V / 83Ω
Operating Temperature -10˚C ~+40˚C
Power Source 100–120VAC or 220–240VAC; 50/60Hz
(Supplied AC mains transformer depends on country requirements)
Power Consumption
38W 50W
Weight (SET) 5.4kg/11.9lb 6.7kg/14.8lb
Dimensions (SET) 420(W)×88(H)×328(D)mm/16.5(W)x3.5(H)x12.9(D)in
* Specifications and design subject to change without notice.
* Remark: 1. All specifications are measured with AES-17 filter.
2. This sytem is used digital Amplifier (PWM Modulation) so the PWM leakage signal will
appear to output terminal, but it doesn’t matter. You can’t hear the PWM leakage sound
because of PWM frequencies is very higher than Audio frequencies.
