PUBLIC ADDRESS AMPLIFIER
7
MA-206/212
5. TEL IN TERMINAL
These terminals are provided for connection with a telephone exchange system for paging purposes.
※ NOTE : When the telephone input is active, all other input signal except AMP IN is able to muted.
6. TEL IN MUTE VOLUME
This is able to control the mute level of all other input signal except AMP IN when the signal is inputted from
the TEL IN terminal.
7. INPUT 1~6 JACK AND INPUT SELECTION SWITCH
INPUT 1~6 are utilized to connect various external sound source devices including MIC, CD, TUNER, etc
1) INPUT 1~3 (Balanced XLR JACK) AND INPUT SELECTION SWITCH
LINE: It can be used as LINE level signal input.
MIC: It can be used as the normal dynamic MIC input.
PHANTOM: It can be used as the condenser MIC input and DC 24V is supplied to the input terminal.
2) INPUT 4~5 (Balanced 6.3Ø Phone JACK) AND INPUT SELECTION SWITCH
LINE: It can be used as LINE level signal input.
MIC: It can be used as the normal dynamic MIC input.
3) INPUT 6 (RCA JACK)
It can be used as an extra stereo input for a stereo source such as a tape deck or CD player.
NOTE: When both inputs are used, the signal is summed and combined.
8. PRIORITY CONTROL VOLUME
The output of INPUT 3~6 are controlled by the priority control volume when the signal is inputted to the INPUT
1~2, LINE IN, CHIME and SIREN.
9. LINE IN
This line-level input connects the unit with an external mixer for expanded input channels.
10. LINE OUT
This line-level output connects the unit with an external mixdown deck or other recording source.
11. AMP IN
This input connects an external mixer or preamp with the unit’s power amp. Inserting a plug into the Amp In jack
will disconnect all input signal from the unit’s internal mixer. Only signal from the external source will be heard.
12. SPEAKER OUTPUT TERMINALS
This terminal is for speaker wire connection.
Connect speakers whose combined impedance is equal to or higher than the rated output impedance, as
shown below.
4Ω (LOW IMPEDANCE) SPK 1~5 (HIGH IMPEDANCE)
15.5V / 4Ω (60W)
EC & Associated : 100V / 167Ω
USA / CANADA & Associated : 70V / 82Ω
22V / 4Ω (120W)
EC & Associated : 100V / 83Ω
USA / CANADA & Associated : 70V / 41Ω
MA-206
MA-212
Model
OUTPUT
