MX-1646
PROFESSIONAL AUDIO MIXER
5. MONO INPUTS
MIC INPUT
- Microphone inputs are on Female XLR. The impedance of this input is approximately 2.2kΩ.
Hi-Z INPUT
- Use this input when connecting sources such as instruments, keyboards or playback devices. This input signal
is summed with the XLR input, but you needn’t worry about phantom power; that will only be supplied from
the XLR. Available input level is about 26dB higher than the XLR input, and impedance of this input is
approximately 50kΩ. If using an unbalanced source, please make sure to link Sleeve and Ring together to
avoid unwanted noise.
.
6. AUX OUTPUTS
The Auxiliary outputs are on TRS jack socket. The nominal level is 0dBu.
7. GROUP OUTPUTS
1/4" TRS socket for inserting external devices. The tip is wired to a ground compensated send, unbalanced
return is via the ring and sleeve. Nominal I/O level is 0dBu.
The "OUTPUT" TRS socket is impedance-unbalanced group signal output.
8. RETURNS INPUTS
L/MONO, R
- A pair of 1/4" TRS jack sockets allow balanced input. Nominal input level is 0dBu, and approximately input
impedance is about 10kΩ.
9. MIX OUTPUT
Male XLR connectors for balanced MIX signal outputs. The nominal output level is 0dBu.
10. AC INLET
Please make sure enclosed power cable matches your AC outlet type.
