MX-1646
PROFESSIONAL AUDIO MIXER
Specifications
Specifications...............................................................
*0dBu=0.775V
MX-1646
INPUT
MIC INPUT XLR3 type female Electrically Balanced
Input Impedance >2.2kΩ
Nominal level -60dBu to -16dBu
Hi-Z INPUT TRS Jack socket Electrically Balanced
Input Impedance >50kΩ
Nominal level -34dBu to +10dBu
STEREO INPUT TRS Jack socket Electrically Balanced
Input Impedance >10kΩ
Nominal level -20dBu to +10dBu
RETURN INPUT TRS Jack socket Electrically Balanced
Input Impedance 10kΩ
Nominal level 0dBu(+20dBu max)
OUTPUT
MIX OUTPUT XLR3 type male Electrically Balanced
Minimum load >600Ω
Nominal level 0dBu (+20dBu max)
GROUP OUTPUT TRS Jack socket Unbalanced
Minimum load >2kΩ
Nominal level 0dBu (+20dBu max)
AUX OUTPUT TRS Jack socket Unbalanced
Minimum load >2kΩ
Nominal level 0dBu (+20dBu max)
MONITOR OUTPUT TRS Jack socket Unbalanced
Minimum load >2kΩ
Nominal level 0dBu (+20dBu max)
PHONES OUTPUT TRS Jack socket Unbalanced
Minimum load >35Ω
Nominal level 100mW / 600Ω
PHANTOM POWER XLR 3 type female
Output Voltage DC +48V
TYPICAL PERFORMANCES
Frequency Response ±1dB (20Hz to 20kHz, MIC to Mix O/P +60dB input gain)
NOISE (MIC EIN)
<
-125dBu (MIC to Mix +60dB input gain with 150 ohms termination A-weight)
Distortion
<
0.1% (1kHz MIC to MIX with +16dB input gain at +20dBu output)
Channel Equalizer High 10kHz, ±15dB Shelf
(Mono) Mid 1.2kHz, ±15dB Peak
Low 100Hz, ±15dB Shelf
Channel Equalizer High 10kHz, ±15dB Shelf
(Stereo) Low 100Hz, ±15dB Shelf
Operating Temperature Range -10℃~+35℃
Humidity 0~90% @35℃
Power Source AC 100V to 240V, 50Hz / 60Hz
Power Consumption 25W
Dimensions 482(W)x105(H)x310(D)mm / 18.98(W)x4.14(H)x12.21(D)in
Weight 5.78kg/12.74lb
* Specifications and design subject to change without notice.
