5
MX-1646
PROFESSIONAL AUDIO MIXER
3. AUXILIARY
Your MX-1646 has 4 auxiliary outputs. These are commonly used for effects, stage monitors and any
additional sends, e.g. camera sound.
Auxiliaries are fed post fader, meaning that the channel’s fader level will affect the level sent to the auxiliary.
These are grouped to allow maximum flexibility.
4. PAN/BAL
Controls the signal’s position in the stereo image. This affects both main MIX outputs as well as any groups to
which the channel is routed. Panning left sends the signal to odd numbered groups only, and panning right
sends it to even numbered groups only.
If, for example, you are panning from hard left to center, you will notice a 3dB drop in the left channel as you
do so. This “panning law” ensures that signals sound equally loud at all pan positions.
5. PEAK/SOLO LED
Displays the channel’s signal peak level and solo function.
The “RED” lamp warns of signal levels approaching the upper headroom limit within about 3dB. We
recommend that you reduce the input gain to avoid unpleasant distortion!
The “GREEN” lamp starts blinking when the solo switch is ON.
6. SOLO SWITCH
Routes the signal to the solo bus for isolated auditioning and detailed metering.
7. CHANNEL FADER
A professional 60mm fader gives you smoth, high-resolution control over the channel level.
8. BUS ASSIGNMENT SWITCHES
Connects the channel signal to each MIX and GROUP buses.
- MIX SWITCH
- GROUP SWITCHES (G1, G2, G3, G4)
