Inter-m SYSTEM-2240G User Manual

MULTI P.A COMBINATION
22
SYSTEM-2240G
Specifications
Specifications
SYSTEM-2240G
Rated Output (T.H.D 1%) 240W
Input Sensitivity MIC 1mV / 20kΩ
/ Impedance AUX 300mV/20kΩ
Frequency MIC 64Hz ~ 32kHz (120Hz ~ 10kHz)
Response AUX 30Hz ~ 30kHz (120Hz ~ 15kHz)
T.H.D MIC 0.18% (Less than 1.0%)
AUX 0.06% (Less than 1.0%)
S/N MIC 60dB (Better than 50dB)
AUX 75dB (Better than 65dB)
EQUALIZER(±10dB) 63, 160, 400, 1k, 2.5k, 6.3k, 16kHz
Pre Amp Output / Impedance 1V/600Ω
Low Output / Impedance 31V/4Ω
Rated Output / Impeadance Transformer 100V/41Ω, 70V/21Ω
- TUNER SECTION
Tuning Range FM 87.5 ~ 108.0 MHz
AM USA:530kHz~1620kHz, EUROPE:522kHz~1620kHz
Antenna Input FM 75Ω Unbal
AM Low Impedance Loop Antenna
Usable Sensitivity FM 2uV (Less than 10uV)
AM 16uV (Less than 100uV)
S/N FM 60dB (Better than 50dB)
AM 50dB (Better than 40dB)
- CASSETTE DECK SECTION
Track System 2-track mono
Record System AC Bias system
Tape Travel Speed 4.76 cm/Sec
Wow & Flutter 0.5%
Frequency Response 125Hz ~ 6.3kHz
S/N 35dB
T.H.D 3%
- COMPACT DISC SECTION
Type Single CD Capacity TRAY type
Frequency Response (±3dB) 100Hz ~ 10kHz
Operating Temperature -10°C ~ +40°C
Power Source 110V–120VAC or 220–240VAC; 50/60Hz
(Supplied AC mains transformer depends on country requirements)
Power Consumption 230W
Weight 23kg/50.7lb
Dimensions 420(W) x 266(H) x 310(D)mm/16.5(W) x 10.5(H) x 12.2(D)in
* Specifications and design subject to change without notice for improvements.
