MULTI P.A COMBINATION
5
SYSTEM-2240G
6. MASTER VOLUME
This knob provides continuous control of the overall system output volume.
7. CHIME BUTTON
Pressing this switch activates the chime circuitry.
8. MIC 1 INPUT
High-impedance input jack for Mic 1. (Note: Mic inputs 2-5 are located on the rear panel.)
9. MIC INPUT LEVEL CONTROLS
Controls the individual levels of mic inputs 1 through 5.
10. CD VOLUME
Controls the level of the CD playback output.
11. TUNER VOLUME
Controls the level of the AM/FM tuner output.
12. DECK VOLUME
Controls the level of Cassette Decks A and B output. Can also be used to control the record level when
dubbing from deck A to deck B.
13. AUX VOLUME
Controls the level of Aux 1 and Aux 2 inputs.
