AC40 Service Manual Page 22
Disassembly
Open the Cabinet
All screws used are Torx
To open the cabinet remove - in total 20 pcs. of 3x8mm screws and 2 pcs. of 3x16mm screws
After removing the screws the top and bottom part can be divided
4
pcs
4
pcs
4
pcs
6
pcs
2
pcs
2
pcs
