AC40 Service Manual Page 23
Remove the PCA Back Board and Side Board
Remove boards be mean of M3x5mm screws. Notice not to unscrew the spacer nuts.
Disconnect the connection cables – when assembling be aware to lock the cables. Disconnect the USB cables from
the Side Board
5
pcs.
4 pcs
Cable lock
