Interface 9840 User Manual

INTERFACE MODEL 9840 VER 6.0.2
SETUP MODE SUMMARY
The table below summarizes the setup mode menus. Detailed information about each
individual item is presented in the following sections.
Setup mode
╠══════
>User Data Entry
║ ╠════════
>>Base Area Ch A/B
║ ╚════════
>>Base Length
║
╠══════
>Analog Output
║ ╚════════
Source → Units → Full → Zero.
║
╠══════
>Sensor Select
║ ╚════════
Channel → Serial Number List → Cal Info.
║
╠══════
>Calibration →
(password access and cell type)
║ ╠════════
>>Cal Check
║ ╠════════
>>Cal by mV / volt
║ ╠════════
>>Cal by Masses or Torque
║ ╠════════
>>Cal by Shunt
║ ╚════════
>>Counts / Inch
║
╠══════
>Limits
║ ╚════════
Select → NO/NC → Enable →
║
Source → Units →Set → Trip →
║
Latch → Reset → Done.
║
╠══════
>System Options
║ ╠════════
>>Printer Baud
║ ╠════════
>>Auto Identify
║ ╠════════
>>Auto Zero Ch A/B
║ ╠════════
>>Com Address
║ ╠════════
>>Com Baudrate
║ ╠════════
>>Com Line Feed
║ ╠════════
>>Retain Tare
╠══════ ╚════════
>>RS232 EOT Char
║
╚══════
>Display Options
╠════════
>>Filter Select
╠════════
>>Decimals Ch A/B
╠════════
>>Count By Ch A/B
╠════════
╚════════
>>Second Line
>>Filter Window
MODEL 9840 PG 13 PUB. 2856-16

Interface 9840 Specifications

General

Brand	Interface
Model	9840
Category	Measuring Instruments
Language	English
