INTERFACE MODEL 9840 VER 6.0.2
RS232 SETUP MODE COMMAND SUMMARY
@(addr)
╠═
U User Data Entry
║ ╠═
V View current settings
║ ╠═
A (channel)(number) # Set Base Area
║ ╚═
L (number) # Set Base Length
║
╠═
A Analog Output
║ ╠═
V View current settings
║ ╚═
S (item)(unit)(full)#(zero)# Set analog output
║
╠═
S Sensor Select
║ ╠═
A View current sensor on A
║ ╠═
B View current sensor on B
║ ╠═
V View current sensors
║ ╠═
S (channel)(serial number)# Select sensor by S/N
║ ╚═
D (serial number)# Delete sensor by S/N
║
╠═
C Calibration
║ ╠═
C Shunt Check load cell
║ ╠═
B (see text for format) Begin load cell calibration
║ ╠═
E Escape load cell calibration
║
║
╠═
╠═
V
MV6
(mv/v constant)#
(see text for format)
Calibrate by mV/V - 1 pt.
Calibrate by mV/V - 6 pt.
╠ ╠═
M (see text for format) Calibrate by Mass 2&5 pt.
║ ╠═
T (see text for format) Calibrate by Torque 2&5 pt.
║ ╠═
S (shunt value Lb)# Calibration by Shunt Value
║ ╚═
I Encoder counts per Inch
║ ╠═
V View counts/inch
║ ╚═
S(number)# Set counts/inch
║
╠═
L(lim) Limits
║ ╠═
V View current settings
║ ╠═
S (see text for format) Setup limit
║ ╠═
E Escape from limit setup
║ ╚═
R Manual reset for latch
║
╠═
O System Options
║ ╠═
V View current settings
║ ╠═
P (baudrate code) Printer baudrate
║ ╠═
I (0 or 1) Auto-Identify load cells
║ ╠═
Z (channel)(0 or 1) Auto-Zero load
║ ╠═
A (new address)# Com Address
║ ╠═
B (baudrate code) Com Baudrate
║ ╠═
L (0 or 1) Com Linefeed
║ ╠═
T (0 or 1) Retain Tare
║ ╚═
E (0 or 1) End of Transmission Char.
║
╚═
D Display Options
╠═
V View current settings
╠═
╠═
F
W
(type)(level)
(see text for format)
Filter select
Filter Window
╠═
D (channel)(number digits) Decimal digits max
╠═
C (channel)(countby code) Smallest count
╚═
2 (B, L, T, or D) 2nd line shows a blank line, limits,
text, or a display.
╚═
T (text) Set the text displayed on 2nd line.
MODEL 9840 PG 31 PUB. 2856-16
